Hapa 400 Spare Parts Stock Items

Part Number Description
199-00-35-145 DISTANCE BOLT FOR 411-17-12-000
199-00-37-021 HANDLE TO ADJUST LABEL HEIGHT
199-00-45-019 LATCH LOCATED ON REMOVABLE COVERS A
199-00-55-052 BEARING (PRESSION ROLLR)
199-00-58-031 BUSHING (GUID. ROLLS TAPE UNWINDER)
199-00-71-018 TOOTHED FLAT BELT (INKING DEVICE DR
199-00-71-040 TOOTHED BELT (HRZNTL)
199-00-71-041 TOOTHED BELT CONVEYOR UNIT
199-00-71-042 TOOTHED BELT (HEIGHT ADJUSTMENT)
199-00-77-028 CLUTCH GEARING
199-00-77-038 SLIDING CLUTCH COATING WIND OFF MOT
199-00-77-044 SLIDING CLUTCH COATING MAIN MOTOR
199-02-03-067 DC/DC converter 15V, 4A
199-02-03-068 DC/DC converter 24V, 8A
199-02-12-374 CLUTCH S1 24
199-02-12-377 PLUG
199-02-15-033 AUT. CUTOUT FAZL 10A
199-02-15-045 SAFETY SWITCH FAZG 1A
199-02-15-047 SAFETY SWITCH FAZG 2A
199-02-15-060 SAFETY SWITCH FAZG 3A
199-02-20-051 TERMINAL SWITCH LABELING HEIGHT
199-02-20-229 APPROXIMATIN INITIATIOR PNP
199-02-20-230 LIMIT SWITCH
199-02-20-235 ROLL LEVER
199-02-20-236 RECTANGULAR ROLL LEVER
199-02-20-237 CODING SWITCH
199-02-20-238 CODING SWITCH
199-02-20-241 PRESS BUTTON (WITHOUT CONTACTS)
199-02-20-242 EMERGENCY OFF BUTTON (WITHOUT CONTA
199-02-20-243 FLIP SWITCH
199-02-20-257 CONTACT BLOCK (LOCKER) (MARKED K-10
199-02-20-258 CONTACT BLOCK (OPENER) (MARKED K-01
199-02-30-053 POTENTIOMETER
199-02-30-056 PTC RESISTOR - B770
199-02-50-011 RECTIFIER SKD 25/02
199-02-50-031 RECTIFIER SKD 50/02
199-02-70-007 PRINT LOGIC SUPPLY FOR OSCILLATOR (
199-02-70-033 PRINT SERVO AMPLIFIER TRIPLE
199-02-70-039 PRINT SM TERMINAL STEP MIDEX
199-02-70-040 PRINT OSCILLATOR (800 steps)
199-02-70-041 PRESELECTION COUNTER 216
199-02-70-042 REGISTERING COUNTER 206
199-02-70-043 SPEEDOMETER 524 AC
199-02-70-054 AC SERVO DRIVER BTS 10-200-0,8P E1
199-02-70-060 PRINT LOGIC SUPPLY FOR AC SERVO
199-02-70-061 AC SERVO DRIVER FOR MAIN MOTOR
199-02-70-062 GENERATOR LOAD MODUL MAIN MOTOR
199-02-85-001 6ES51028MA02SPS CENTRAL COMPONENTRY
199-02-85-010 SPS DIGITAL INPUT GROUP, 4 INPUTS
199-02-85-011 6ES54218MA12 - SPS DIGITAL INPUT GR
199-02-85-020 SPS DIGITAL OUTPUT GROUP, 4 OUTPUTS
199-02-85-040 6ES57008MA11 - RACK TERMINAL (BUS M
199-06-03-044 PEL TUBE í 3mm, l=1m
199-06-55-003 DISPOSABLE AIR FILTER
199-06-55-004 PEL SWITCH
199-08-10-046 STEPPING MOTOR
199-08-10-112 BRUSH HOLDER
199-08-10-113 GRAPHITE BRUSH
199-08-10-117 GRAPHITE BRUSH MAIN MOTOR
199-08-10-118 GRAPHITE BRUSH SPEEDING GENERATOR
199-08-10-129 FILTER PAD
199-08-10-140 STEPPING MOTOR
199-08-10-159 EXHAUST FAN WITH BEARINGS
199-08-20-018 LOCKING MAGNET
199-08-30-089 SEMICONDUCTOR RELAY 25D
199-08-30-155 MOTOR SAFETY SWITCH PKZM1-0,4
199-08-30-158 MOTOR SAFETY SWITCH PKZM1-1,6
199-08-30-163 MOTOR SAFETY SWITCH PKZM1-16
199-08-30-166 CONTACTOR DIL OOAM-10
199-08-30-167 CONTACTOR DIL OAM
199-08-30-168 CONTACTOR 11 DILM
199-08-30-181 OPTO COUPLER EMO1-OV-24DC
199-08-30-182 OPTO COUPLER EMO1-OV-12DC
199-08-30-215 ELECTRONIC COUPLER
199-10-32-005 LUMINOUS DIODE RED
199-10-32-006 LUMINOUS DIODE YELLOW
199-10-32-007 LUMINOUS DIODE GREEN
411-17-01-017 BOLT
411-17-01-025 SPRING
411-17-04-005 ROD
411-17-04-011 CUTTING KNIFE 85 mm
411-17-04-016 CUTTING KNIFE 120 mm
411-17-06-072 SM-PRESSION ROLLER COMPLETE FOR 85M
411-17-06-107 SM-DRIVE ROLLER COMPLETE FOR 85MM C
411-17-06-117 SUPPORT FOR PRESSION ROLLER
411-17-06-119 TENSION SPRING (PRESSION ROLLER)
411-17-06-120 HOLDER FOR ASSEMBLY FOR PRESSION RO
411-17-06-122 BACKING PLATE FOR ROLLER FOR ADVANC
411-17-06-129 RING 9MM WIDTH (LOCKING COLLAR ON C
411-17-06-140B METALIZED DRIVE ROLLER
411-17-06-203 AXLE
411-17-06-207 SM-DRIVE ROLLER COMPLETE FOR 120MM
411-17-06-218 AXLE FOR PRESSION ROLLER ASSEMBLY F
411-17-07-043 STAPLE SHEET (REMOVABLE PLATE AT TO
411-17-11-002 GRAPHITE TUBE FOR VACUUM PLATE VENT
411-17-11-010 DRUM KNIFE 85 mm-(SEE NOTES)
411-17-11-013 SENSOR PT100
411-17-11-014 HEATING CARTRIDGE 85 mm
411-17-11-015 FLANGE PACKING
411-17-11-033 DRUM KNIFE 120 mm
411-17-11-034 HEATING CARTRIDGE 120 mm
411-17-12-000 PRINT LABELING HEAT CONTROLLER
411-21-02-004 SHAFT
411-21-02-050 SYNTHETIC TOOTHED WHEEL (INKING DEV
411-21-02-076 TENSION SPRING (STAMP)
411-21-02-087 SHIFT GEAR
411-21-02-114 INKING ROLLER HOLDER LEFT HAND
411-21-02-115 INKING ROLLER HOLDER RIGHT HAND
411-21-02-116 SPRING FOR HOLDER
411-21-03-046 RIGHT BLOCK, HOLDER FOR MODIFIED SP
411-21-03-051 LEVER RIGHT HAND CPL. (BATHING FNTN
411-21-03-052 LEVER LEFT HAND CPL. (BATHING FNTN.
411-21-03-054 SPRING
411-21-03-055 LEFT BLOCK, HOLDER FOR MODIFIED SPR
411-21-03-066 INK CONTAINER INCL. LOCKING PIVOT 4
411-21-04-005 INKING ROLLER COMPLETE
411-21-06-005 NICKEL PLATED VENT TUBE
411-30-07-008 BEVELED WASHER FOR CLAMPING LEVER C
411-30-07-009 CLAMPING LEVER COMPLETE
411-30-09-001 BLOCK HOLDER SHEET - PRINT STA #1
411-30-09-002 BLOCK HOLDER SHEET - PRINT STA #3
411-30-09-005 BLOCK HOLDER SHEET - PRINT STA #2
411-30-09-006 BLOCK HOLDER SHEET - PRINT STA #4
411-30-09-008 BLOCK HOLDER SHEET FOR STA. 2, 3 &
411-30-09-010 BLOCK HOLDER SHEET SHORT/PRNT STA#1
413-00-00-017 CLUTCH FOR VERTICAL BELT
413-00-00-030 SLIDING RAIL
413-02-03-009 BOTTLE CONVEYOR LOGIC
413-08-01-017 SPRING FOR POTENTIOMETER
413-10-03-012B BELT HOLDING AXLE
413-10-17-101 PRESSION BELT 17mm HT. 1000MM LONG
413-10-20-203 GUIDING PRESSION SLIDE FEEDING 20mm
413-10-20-205 SPONGE FOR PRESSION BELT 20mm HEIGH
413-10-20-206 GUIDING PRESSION SLIDE TAKE OFF 20m
413-10-20-210 GUIDING PRESSION SLIDE FEED 17MM HE
413-10-20-212 GUIDING PRESSION SLIDE TAKE OFF 17M
413-10-20-300B BACK OF BELT PRESSION SLIDE 20mm HE
413-10-30-101 PRESSION BELT 30mm Ht. (SEE NOTES)
413-10-30-205 SPONGE PRESSION BELT 30mm HEIGHT
413-10-40-101 PRESSION BELT 40mm HT. (SEE NOTES)
413-10-40-203 GUIDING PRESSION SLIDE FEEDING RIGH
413-10-40-205 SPONGE PRESSION BELT 40mm HEIGHT
413-10-40-206 GUIDING PRESSION SLIDE TAKE OFF LEF
413-10-40-300B BACK OF BELT PRESSION SLIDE 40mm HE
413-14-00-012 BELT GUIDING (VERTICAL BELT)
413-14-20-011 CONVEYOR BELT 20mm HT. (SEE NOTES)
413-14-20-020B BACK OF BELT CONVEYOR UNIT 20mm HEI
413-14-30-011 CONVEYOR BELT 30mm HT. (SEE NOTES)
413-14-30-020B BACK OF BELT CONVEYOR UNIT 30mm HEI
413-14-40-011 CONVEYOR BELT 40mm HT. (SEE NOTES)
413-14-40-012 GUIDING CONVEYOR UNIT LEFT HAND 40m
413-14-40-020B BACK OF BELT CONVEYOR UNIT 40mm HEI
413-15-20-012 GUIDING CONVEYOR UNIT RIGHT HAND 20
413-15-30-012 GUIDING CONVEYOR UNIT RIGHT HAND 30
413-15-40-012 GUIDING CONVEYOR UNIT RIGHT HAND 40
414-13-00-020 FAN
414-14-00-012 PLATE LIST S1 24 (PLUG LEDGE)
414-19-01-011 ROLL (GUID. ROLLS TAPE UNWINDER)
414-21-60-009B POLYESTER SELF-ADHESIVE FOIL (ASSOR
416-00-30-009B CIRCUIT BOARD
416-00-40-009 PNP - NPN CONVERTER
421-21-02-010 SPROCKET ON FAR LEFT END OF PRINT S
BS-8RF CLIP
